Model for a Self-propelled Cart based on a drawing by Leonardo da Vinci

Model for a Self-propelled Cart based on a drawing by Leonardo da Vinci

Model for a Self-propelled Cart based on a drawing by Leonardo da Vinci (1452-1519), Italian artist and polymath; Codex Atlanticus, folio 812 v. Considered the forerunner to the modern automobile, in a note referring to this model, Leonardo da Vinci defines the cart as man's most important invention; This model of a Self-propelled Cart demonstrates the implementation of his knowledge of the most complicated self-propelling mechanisms for theatrical events. The cart would be operated by a manual loading system with leaf springs, which through a series of complicated cog-wheels would transmit the stored power to the drive wheels. The independent drives were connected both to the wheels and a device that differentiated the speed, while a shaft, also with a wheel, served to steer the cart in the right direction.
