Model of a 12-Pounder Carronade on a Slide, Model of a carronade on cover. The 19.7 long carronade has a caliber of 17 mm. The inscriptions are engraved on the barrel, along with crossed anchors and palm branches. The barrel has a concave elevation, a visor on the middle decorative band and a front band, a refraction ring and a feather screw through the grape. The upper carriage has a light trapezoidal body with brass fittings and rings, the front and back are rounded. Against the rear the box in brass fittings, on top of the track for the elevering screw and at the front the ears through which the tapas runs, the vertebral bolt is missing. The lower carriage is a wooden window, rounded at the front, with a slot for the vertebral bolt and partly with brass fittings and equipped with a spindle bolt resting in a block, a securing plate is fitted on the underside slightly to the rear. At the rear, the lower carriage is supported by a protruding crossbar, with wheels with their axes radial to the spindle bolt. In the middle the carriage is also reinforced by a crossbar., anonymous, Rotterdam (possibly), 1800, wood (plant material), brass (alloy), h 16.1 cm × w 27 cm × d 10.2 cm × c 17 mm × w 3 kg.

Model of a 12-Pounder Carronade on a Slide, Model of a carronade on cover. The 19.7 long carronade has a caliber of 17 mm. The inscriptions are engraved on the barrel, along with crossed anchors and palm branches. The barrel has a concave elevation, a visor on the middle decorative band and a front band, a refraction ring and a feather screw through the grape. The upper carriage has a light trapezoidal body with brass fittings and rings, the front and back are rounded. Against the rear the box in brass fittings, on top of the track for the elevering screw and at the front the ears through which the tapas runs, the vertebral bolt is missing. The lower carriage is a wooden window, rounded at the front, with a slot for the vertebral bolt and partly with brass fittings and equipped with a spindle bolt resting in a block, a securing plate is fitted on the underside slightly to the rear. At the rear, the lower carriage is supported by a protruding crossbar, with wheels with their axes radial to the spindle bolt. In the middle the carriage is also reinforced by a crossbar., anonymous, Rotterdam (possibly), 1800, wood (plant material), brass (alloy), h 16.1 cm × w 27 cm × d 10.2 cm × c 17 mm × w 3 kg
