Título: Diagram of a Linotype Machine
Descripción: Ver traducción automática
Diagram of a Linotype Machine, a "line casting" machine used in printing: A) Matrix with 7 teeth on either side of deep notch. B) Casting the slug line of matrices and space bars clamped against the face of the mould wheel. Lever depressors pump plunger, forcing molten metal through the spout and fills the wheel slot and type depressions in matrices. This 'slug' moved to join previously cast type. C) Matrices falling from distributor bar into a magazine. Dated 20th century
Diagram of a Linotype Machine, a "line casting" machine used in printing: A) Matrix with 7 teeth on either side of deep notch. B) Casting the slug line of matrices and space bars clamped against the face of the mould wheel. Lever depressors pump plunger, forcing molten metal through the spout and fills the wheel slot and type depressions in matrices. This 'slug' moved to join previously cast type. C) Matrices falling from distributor bar into a magazine. Dated 20th century
Crédito: Album / World History Archive
Autorizaciones: ? Cesión de modelo: No - ? Cesión de propiedad: No
¿Preguntas relacionadas con los derechos?
¿Preguntas relacionadas con los derechos?
Tamaño imagen: 3584 × 5852 px | 60.0 MB
Tamaño impresión: 30.3 × 49.5 cm | 1411.0 × 2303.9 in (300 dpi)
